Mitutoyo Dial Indicator Lug Back Jeweled Bearing 1mm Range | 0.001mm Graduation

SERIES 2 — Mitutoyo Standard Type Dial Indicator

• Standard 0.001 mm graduation dial indicators having a bezel with an outside diameter of 57 mm.

• The bezel clamp and lifting lever (optional) can be attached to either the right or left side. These parts can be easily installed and removed without tools.

• Watertight assembly of bezel and crystal as well as the use of an O-ring prevents water or oil penetration.

• The stem and spindle are made of high-strength quench-hardened stainless steel suitable for heavy-duty use.

• A carbide contact point is used.

• A special alloy is used for the sector gears to provide improved wear resistance.

• The indicator uses jeweled bearings, providing excellent indication sensitivity and durability.

• Application of an anti-reflective and hard surface coating improves scale visibility along with scratch and chemical resistance.

Technical Data:

Digital/Analog: Analog

Inch-Metric: Metric

Functions: ISO type

Range: 1 mm

Range per rev.: 0.1 mm

Graduation: 0.001 mm

Graduation: 0.001

Scale: 0-100

Measuring force: 0.4-1.8 N

MPE any 1/10 revolution: 2.5 µm

MPE any 1/2 revolution: 4 µm

MPE any 1 revolution: 4.5 µm

MPE measuring range: 5 µm

H MPE (Hysteresis): 2 µm

R MPE (Repeatability): 1 µm

Stem: 8 mm

Contact point: Carbide tipped, thread: M 2.5 x 0.45 mm

Continuous dial: Yes

Double scale spacing: Yes

Shockproof: Yes

fu: 2 µm

Mass: 149 g

Model #: 2110A-10

MADE IN JAPAN
